Description
| PARTICULARS | DETAILS |
| Power Range | 0.5HP to 1.0 HP |
| Voltage Range | 200V – 240V, 50Hz, AC Single phase |
| Speed | 1420 RPM |
| Motor Type | High torque Capacitor start motor for DMS series / High torque Capacitor start and Capacitor run motor for DMS N series |
| Head | Maximum 36 M |
| Discharge | Maximum 59 LPM |
| Operating Pressure | Maximum 15 bar |
- Rugged single phase TEFC motor with dynamically balanced rotor
- Suitable for 200 – 240 V, 50 Hz power supply
- Rigid and accurate cast iron castings
- Highly wear resistant bronze impeller
- Carbon Vs Ceramic mechanical seal
| PARTCULARS | DETAILS |
| Stator Frame | Cast Iron |
| Bearings | Deep groove ball bearings |
| Rotor shaft | Carbon Steel |
| Shaft sleeve | Bronze |
| Casing | Cast Iron |
| Cover dome | Cast Iron |
| Impeller | Bronze |
| Sealing Arrangements | Carbon Vs Ceramic Mechanical seal. |
